使用Matomo打造百万PV的网站访问统计系统

centos7 运维 · systemofdown · 于 5个月前 发布 · 274 次阅读

服务器配置

每月跟踪100万次或更少的页面浏览量

一台服务器足以同时承载数据库和应用程序服务器 ,应用服务器最低推荐配置:

4 CPU, 8 GB RAM, 250GB SSD .

  • Nginx
  • PHP 8.x
  • MySQL 8+

php 推荐配置 vim /etc/php.ini

以下参数对号入座一下

memory_limit = 2G
max_execution_time = 0
log_errors = On
display_errors=Off

MySQL 推荐配置 vim /etc/my.cnf

通过将MySQL临时目录移动到tmpfs来提升性能

[mysqld]
tmpdir = /run/mysqld

重启服务

service mysqld restart

确认是否生效,登录mysql

# mysql
mysql> SHOW VARIABLES LIKE 'tmpdir';
+---------------+-------------+
| Variable_name | Value       |
+---------------+-------------+
| tmpdir        | /run/mysqld |
+---------------+-------------+

其他参数

;提高吞吐量
innodb_flush_log_at_trx_commit=2
;如果您每月跟踪的操作少于100万次
;您可以将下面的值降低到512M
max_allowed_packet = 1G
wait_timeout = 28800

Redis 推荐配置

安装php扩展

yum install php-pecl-redis -y

修改配置文件 config/config.ini.php

[Cache]
backend = chained

[ChainedCache]
backends[] = array
backends[] = redis

[RedisCache]
host = "127.0.0.1"
port = 6379
timeout = 0.0
password = ""
database = 14
; In case you are using queued tracking: Make sure to configure a different database! Otherwise queued requests will be flushed

Nginx 配置

新建配置文件 vim /etc/nginx/conf.d/matomo.conf

server {
    listen [::]:80; # remove this if you don't want Matomo to be reachable from IPv6
    listen 80;
    server_name matomo.example.com;
    # Redirect all HTTP requests to HTTPS with a 301 Moved Permanently response.
    location / {
        return 301 https://$host$request_uri;
    }
}
server {
    listen [::]:443 ssl http2; # remove this if you don't want Matomo to be reachable from IPv6
    listen 443 ssl http2;
    server_name matomo.example.com; # list all domains Matomo should be reachable from
    access_log /var/log/nginx/matomo.access.log;
    error_log /var/log/nginx/matomo.error.log;

    ## uncomment if you want to enable HSTS with 6 months cache
    ## ATTENTION: Be sure you know the implications of this change (you won't be able to disable HTTPS anymore)
    #add_header Strict-Transport-Security max-age=15768000 always;

    ## replace with your SSL certificate
    ssl_certificate /etc/letsencrypt/live/matomo.example.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/matomo.example.com/privkey.pem;

    include ssl.conf; # if you want to support older browsers, please read through this file

    add_header Referrer-Policy origin always; # make sure outgoing links don't show the URL to the Matomo instance
    add_header X-Content-Type-Options "nosniff" always;
    add_header X-XSS-Protection "1; mode=block" always;

    root /var/www/matomo/; # replace with path to your matomo instance

    index index.php;

    ## only allow accessing the following php files
    location ~ ^/(index|matomo|piwik|js/index|plugins/HeatmapSessionRecording/configs)\.php$ {
        include snippets/fastcgi-php.conf; # if your Nginx setup doesn't come with a default fastcgi-php config, you can fetch it from https://github.com/nginx/nginx/blob/master/conf/fastcgi.conf
        try_files $fastcgi_script_name =404; # protects against CVE-2019-11043. If this line is already included in your snippets/fastcgi-php.conf you can comment it here.
        fastcgi_param HTTP_PROXY ""; # prohibit httpoxy: https://httpoxy.org/
        fastcgi_pass unix:/var/run/php/php7.2-fpm.sock; #replace with the path to your PHP socket file
        #fastcgi_pass 127.0.0.1:9000; # uncomment if you are using PHP via TCP sockets (e.g. Docker container)
    }

    ## deny access to all other .php files
    location ~* ^.+\.php$ {
        deny all;
        return 403;
    }

    ## serve all other files normally
    location / {
        try_files $uri $uri/ =404;
    }

    ## disable all access to the following directories
    location ~ ^/(config|tmp|core|lang) {
        deny all;
        return 403; # replace with 404 to not show these directories exist
    }

    location ~ /\.ht {
        deny  all;
        return 403;
    }

    location ~ js/container_.*_preview\.js$ {
        expires off;
        add_header Cache-Control 'private, no-cache, no-store';
    }

    location ~ \.(gif|ico|jpg|png|svg|js|css|htm|html|mp3|mp4|wav|ogg|avi|ttf|eot|woff|woff2)$ {
        allow all;
        ## Cache images,CSS,JS and webfonts for an hour
        ## Increasing the duration may improve the load-time, but may cause old files to show after an Matomo upgrade
        expires 1h;
        add_header Pragma public;
        add_header Cache-Control "public";
    }

    location ~ ^/(libs|vendor|plugins|misc|node_modules) {
        deny all;
        return 403;
    }

    ## properly display textfiles in root directory
    location ~/(.*\.md|LEGALNOTICE|LICENSE) {
        default_type text/plain;
    }
}

Matomo系统配置

创建新的配置文件: path/to/matomo/config/common.config.ini.php

; <?php exit; ?> DO NOT REMOVE THIS LINE
;
; This common.config.ini.php file is read right before config.ini.php
[General]
; Always use SSL and redirect http->https in Matomo
force_ssl = 1

; Do not allow users to trigger the Matomo archiving process.
; Ensures that no unexpected data processing triggers from UI or API.
enable_browser_archiving_triggering = 0

; Uncomment to make sure that API requests with
; a &segment= parameter will not trigger archiving
; browser_archiving_disabled_enforce = 1

;Uncomment to disable historical archive processing
;when a new plugin is installed and may try process historical data
;rearchive_reports_in_past_last_n_months =
;rearchive_reports_in_past_exclude_segments = 1

; Disable OPTIMIZE TABLE statement which can create dead-locks
; and prevent MySQL backups
enable_sql_optimize_queries = 0

; Enable Matomo application logging to both file and screen
[log]
log_writers[] = "file"
log_writers[] = "screen"

; Matomo logs (WARN, ERROR) are written in matomo/tmp/logs/matomo.log
logger_file_path = tmp/logs/matomo.log

[CustomReports]
custom_reports_max_execution_time = 2700
custom_reports_disabled_dimensions = "CoreHome.VisitLastActionDate"

安装 QueuedTracking 插件

  1. 后台插件市场安装 QueuedTracking

  2. 插件设置

    • Backend = redis
    • Queue enabled 打勾
    • 多少个请求做一次批处理 = 50
  3. 计划任务配置

* * * * * php /path/to/matomo/console queuedtracking:process --no-ansi >/dev/null 2>&1

报告自动归档 Auto-Archiving

后台要设置,在浏览器中查看报告时进行归档为

计划任务配置

5 * * * * /usr/bin/php /path/to/matomo/console core:archive --url=http://example.org/matomo/ > /dev/null

参考:

本文由 systemofdown 创作,采用 知识共享署名 3.0 中国大陆许可协议 进行许可。 可自由转载、引用,但需署名作者且注明文章出处。
