yii\bootstrap4\Progress - Yii2 类参考手册

Class yii\bootstrap4\Progress

全部 | 属性 Properties | 方法 Methods | 事件 Events
Inheritanceyii\bootstrap4\Progress » yii\bootstrap4\Widget » yii\base\Widget » yii\base\Component » yii\base\BaseObject
Implementsyii\base\Configurable, yii\base\ViewContextInterface
Uses Traitsyii\bootstrap4\BootstrapWidgetTrait

Progress renders a bootstrap progress bar component.

For example,

// default with label
echo Progress::widget([
    'percent' => 60,
    'label' => 'test'
]);
// or
echo Progress::widget([
    'bars' => [
        ['percent' => 60, 'label' => 'test']
    ]
]);

// styled
echo Progress::widget([
    'percent' => 65,
    'barOptions' => ['class' => 'bg-danger']
]);
// or
echo Progress::widget([
    'bars' => [
        ['percent' => 65, 'options' => ['class' => 'bg-danger']]
    ]
]);

// striped
echo Progress::widget([
    'percent' => 70,
    'barOptions' => ['class' => ['bg-warning', 'progress-bar-striped']]
]);
// or
echo Progress::widget([
    'bars' => [
        ['percent' => 70, 'options' => ['class' => ['bg-warning', 'progress-bar-striped']]]
    ]
]);

// striped animated
echo Progress::widget([
    'percent' => 70,
    'barOptions' => ['class' => ['bg-success', 'progress-bar-animated', 'progress-bar-striped']]
]);
// or
echo Progress::widget([
    'bars' => [
        ['percent' => 70, 'options' => ['class' => ['bg-success', 'progress-bar-animated', 'progress-bar-striped']]]
    ]
]);

// stacked bars
echo Progress::widget([
    'bars' => [
        ['percent' => 30, 'options' => ['class' => 'bg-danger']],
        ['percent' => 30, 'label' => 'test', 'options' => ['class' => 'bg-success']],
        ['percent' => 35, 'options' => ['class' => 'bg-warning']],
    ]
]);

请参阅 https://getbootstrap.com/docs/4.2/components/progress/.

Public Properties

隐藏继承的属性 Hide inherited properties

属性Property类型 Type简介 Description定义在 Defined By
$autoIdPrefix string The prefix to the automatically generated widget IDs. yii\base\Widget
$barOptions array The HTML attributes of the bar. yii\bootstrap4\Progress
$bars array A set of bars that are stacked together to form a single progress bar. yii\bootstrap4\Progress
$behaviors yii\base\Behavior[] List of behaviors attached to this component yii\base\Component
$clientEvents array The event handlers for the underlying Bootstrap JS plugin. yii\bootstrap4\BootstrapWidgetTrait
$clientOptions array The options for the underlying Bootstrap JS plugin. yii\bootstrap4\BootstrapWidgetTrait
$counter integer A counter used to generate $id for widgets. yii\base\Widget
$id string ID of the widget. yii\base\Widget
$label string The button label. yii\bootstrap4\Progress
$options array The HTML attributes for the widget container tag. yii\bootstrap4\Widget
$percent integer The amount of progress as a percentage. yii\bootstrap4\Progress
$stack yii\base\Widget[] The widgets that are currently being rendered (not ended). yii\base\Widget
$view yii\web\View The view object that can be used to render views or view files. yii\bootstrap4\BootstrapWidgetTrait
$viewPath string The directory containing the view files for this widget. yii\base\Widget

Public Methods

隐藏继承的方法 Hide inherited methods

方法 Method简介 Description定义在 Defined By
__call() Calls the named method which is not a class method. yii\base\Component
__clone() This method is called after the object is created by cloning an existing one. yii\base\Component
__construct() Constructor. yii\base\BaseObject
__get() Returns the value of a component property. yii\base\Component
__isset() Checks if a property is set, i.e. defined and not null. yii\base\Component
__set() Sets the value of a component property. yii\base\Component
__unset() Sets a component property to be null. yii\base\Component
afterRun() This method is invoked right after a widget is executed. yii\base\Widget
attachBehavior() Attaches a behavior to this component. yii\base\Component
attachBehaviors() Attaches a list of behaviors to the component. yii\base\Component
beforeRun() This method is invoked right before the widget is executed. yii\base\Widget
begin() Begins a widget. yii\base\Widget
behaviors() Returns a list of behaviors that this component should behave as. yii\base\Component
canGetProperty() Returns a value indicating whether a property can be read. yii\base\Component
canSetProperty() Returns a value indicating whether a property can be set. yii\base\Component
className() Returns the fully qualified name of this class. yii\base\BaseObject
detachBehavior() Detaches a behavior from the component. yii\base\Component
detachBehaviors() Detaches all behaviors from the component. yii\base\Component
end() Ends a widget. yii\base\Widget
ensureBehaviors() Makes sure that the behaviors declared in behaviors() are attached to this component. yii\base\Component
getBehavior() Returns the named behavior object. yii\base\Component
getBehaviors() Returns all behaviors attached to this component. yii\base\Component
getId() Returns the ID of the widget. yii\base\Widget
getView() yii\bootstrap4\BootstrapWidgetTrait
getViewPath() Returns the directory containing the view files for this widget. yii\base\Widget
hasEventHandlers() Returns a value indicating whether there is any handler attached to the named event. yii\base\Component
hasMethod() Returns a value indicating whether a method is defined. yii\base\Component
hasProperty() Returns a value indicating whether a property is defined for this component. yii\base\Component
init() Initializes the widget. yii\bootstrap4\Progress
off() Detaches an existing event handler from this component. yii\base\Component
on() Attaches an event handler to an event. yii\base\Component
render() Renders a view. yii\base\Widget
renderFile() Renders a view file. yii\base\Widget
run() Executes the widget. yii\bootstrap4\Progress
setId() Sets the ID of the widget. yii\base\Widget
setView() Sets the view object to be used by this widget. yii\base\Widget
trigger() Triggers an event. yii\base\Component
widget() Creates a widget instance and runs it. yii\base\Widget

Protected Methods

隐藏继承的方法 Hide inherited methods

方法 Method简介 Description定义在 Defined By
registerClientEvents() Registers JS event handlers that are listed in $clientEvents. yii\bootstrap4\BootstrapWidgetTrait
registerPlugin() Registers a specific Bootstrap plugin and the related events yii\bootstrap4\BootstrapWidgetTrait
renderBar() Generates a bar yii\bootstrap4\Progress
renderProgress() Renders the progress. yii\bootstrap4\Progress

事件 Events

隐藏继承的事件 Hide inherited events

事件 Event类型 Type简介 Description定义在 Defined By
EVENT_AFTER_RUN yii\base\WidgetEvent An event raised right after executing a widget. (available since version 2.0.11) yii\base\Widget
EVENT_BEFORE_RUN yii\base\WidgetEvent An event raised right before executing a widget. (available since version 2.0.11) yii\base\Widget
EVENT_INIT yii\base\Event An event that is triggered when the widget is initialized via init(). (available since version 2.0.11) yii\base\Widget

属性详情 Property Details

$barOptions public property (available since version 2.0.6)

The HTML attributes of the bar. This property will only be considered if $bars is empty

请参阅 yii\helpers\Html::renderTagAttributes() for details on how attributes are being rendered.

public array $barOptions = []
$bars public property

A set of bars that are stacked together to form a single progress bar. Each bar is an array of the following structure:

[
    // required, the amount of progress as a percentage.
    'percent' => 30,
    // optional, the label to be displayed on the bar
    'label' => '30%',
    // optional, array, additional HTML attributes for the bar tag
    'options' => [],
]
public array $bars = null
$label public property

The button label. This property will only be considered if $bars is empty

public string $label = null
$percent public property

The amount of progress as a percentage. This property will only be considered if $bars is empty

public integer $percent = 0

方法详情 Method Details

init() public method

Initializes the widget.

This method will register the bootstrap asset bundle. If you override this method, make sure you call the parent implementation first.

public void init ( )
renderBar() protected method

Generates a bar

protected string renderBar ( $percent, $label = '', $options = [] )
$percent integer

The percentage of the bar
$label string

, optional, the label to display at the bar
$options array

The HTML attributes of the bar
return string

The rendering result.
renderProgress() protected method

Renders the progress.

protected string renderProgress ( )
return string

The rendering result.
throws yii\base\InvalidConfigException

if the "percent" option is not set in a stacked progress bar.
run() public method

Executes the widget.

public string run ( )
return string

The result of widget execution to be outputted.
throws yii\base\InvalidConfigException
